17 July, 2024For an economical, safe and high-performance alternative to pipes made from traditional materials.
FITT Bluforce PVC-A pipes for transporting fluids under pressure in water networks and aqueducts are manufactured by FITT, the first manufacturer to bring PVC-A polymer alloy technology to Italy.
An increased lifespan of water networks and aqueducts, lower overall works cost, superior reliability in water service delivery, and a reduction of maintenance costs over time: these benefits are guaranteed by PVC-A pipes when compared to old cast iron, steel and polyethylene pipes.
Thanks to its characteristics — ductility, durability, and handling — FITT Bluforce PVC-A piping facilitates work onsite, by ensuring integrity and efficiency in water networks even in the event of knocks, improper pipe lines, or serious weather conditions.
All data is calculated for DN200 (PE100, PVC-U and PVC-A: PN16) piping. The flow rate is calculated for a 1,000-metre straight line with an internal pressure of 12 bar. The laying speed is calculated not including digging and refilling the trench. The handling directions are given for 6 metres of piping and in accordance with the parameters of Legislative Decree 81/2008.
FITT Bluforce DN 160 PN 16 laying – 2.300 meters – Rovigo (IT)
FITT Bluforce manufacturing and testing
PVC-A piping: the high performance solution for aqueducts and irrigation systems
RESISTANCE TO IMPACTS
Thanks to its always ductile behaviour, FITT Bluforce RJ guarantees high resistance to impacts even at low temperatures, facilitating site operations.
ANTI-CORROSION
FITT Bluforce RJ withstands electrochemical corrosion and is inert to chlorine dioxide used to make the mains water drinkable.
DURABILITY
The polymer alloy (PVC-A) technology makes FITT Bluforce RJ highly resistant to crack propagation. This characteristic guarantees a longer service life of the piping and reduced maintenance
ADVANCED JOINTING SYSTEM
FITT Bluforce RJ adopts the socket-based Bulldog® jointing system with integrated and immovable seal, which ensures rapid assembly of the pipe and both hydraulic and mechanical tightness
COMPATIBLE SYSTEM
FITT Bluforce RJ can be inserted in new and existing systems thanks to its compatibility with cast iron, steel, PVC-U and HDPE couplings.
IMPERMEABILITY TO POLLUTANTS
FITT Bluforce RJ is impermeable to the pollutants contained in the soil protecting the conveyed water against potential contamination.
RESPECTS THE ENVIRONMENT
Thanks to its reduced thickness, FITT Bluforce RJ can be manufactured with lower amounts of raw materials and energy required for their transformation. PVC-A is 100% recyclable.
LOWER MANAGEMENT COSTS
FOR THE PRINCIPAL
FITT Bluforce RJ reduces both the time required to build new pipelines and the costs associated with their maintenance.
EASIER LAYING FOR THE COMPANY
FITT Bluforce RJ guarantees faster, easier and safer pipe laying and drastically reduces potential errors during assembly, always ensuring positive test and commissioning.
The pipes are available in 6-metre bars
DN [mm] |
PN10 THK [mm] |
PN16 THK [mm] |
PN20 THK [mm] |
Socket length [mm] |
Lm [mm] |
---|---|---|---|---|---|
90 | – | 4,0 | 4,9 | 150 | 120 |
110 | 3,1 | 4,9 | 6,0 | 150 | 145 |
125 | 3,5 | 5,5 | 6,8 | 160 | 165 |
140 | 3,9 | 6,2 | 7,6 | 160 | 180 |
160 | 4,5 | 7,0 | 8,7 | 180 | 205 |
200 | 5,6 | 8,8 | 10,9 | 190 | 260 |
225 | 6,3 | 9,9 | 12,2 | 200 | 270 |
250 | 7,0 | 11,0 | 13,6 | 210 | 320 |
280 | 7,8 | 12,3 | 15,2 | 210 | 330 |
315 | 8,8 | 13,8 | 17,1 | 220 | 390 |
355 | 9,9 | 15,6 | 19,2 | 220 | 440 |
400 | 11,2 | 17,5 | 21,7 | 230 | 490 |
500 | 13,9 | 21,9 | – | 240 | 610 |
630 | 17,5 | 27,6 | – | 330 | 780 |
The pipes are available in 6-metre bars
DN [mm] |
PN10 THK [mm] |
PN16 THK [mm] |
PN20 THK [mm] |
Socket length [mm] |
Lm [mm] |
---|---|---|---|---|---|
90 | – | 4,0 | 4,9 | 165 | 120 |
110 | 3,1 | 4,9 | 6,0 | 170 | 145 |
160 | 4,5 | 7,0 | 8,7 | 200 | 205 |
200 | 5,6 | 8,8 | 10.9 | 230 | 260 |
225 | 6,3 | 9,9 | 12,2 | 245 | 270 |
250 | 7,0 | 11,0 | 13,6 | 260 | 320 |
315 | 8,8 | 13,8 | 17,1 | 300 | 390 |
400 | 11,2 | 17,5 | 21,7 | 330 | 490 |
DN [mm] |
PN16 THK [mm] |
45° [mm] |
90° [mm] |
Socket length [mm] |
Lm [mm] |
---|---|---|---|---|---|
90 | 4,0 | (A) 280 x (B) 900 | (A) 380x (B) 900 | 165 | 124 |
110 | 4,9 | (A) 350 x (B) 850 | (A) 450 x (B) 1.000 | 170 | 148 |
160 | 7,0 | (A) 330 x (B) 1.050 | (A) 530 x (B) 1.200 | 200 | 210 |
200 | 8,8 | (A) 720 x (B) 1.500 | (A) 750 x (B) 2.000 | 230 | 260 |
225 | 9,9 | ** | ** | 245 | 285 |
250 | 11,0 | ** | ** | 260 | 320 |
315 | 13,8 | ** | ** | 300 | 398 |
400 | 17,5 | ** | ** | 330 | 500 |
(**) available on request
